Description
The RX360, with a 3-megapixel resolution and a DICOM-GSDF luminance characteristic curve, is ideal for precisely displaying monochrome and color images produced by radiological systems.
Excellent Image Quality for the Finest Detail
Thanks to the high 3 Megapixels (color) resolution, a strong contrast ratio of 1500:1, and stable brightness of up to 1100 cd/m2, Eizo Radiforce RX360 offers excellent image quality. Even the differences between the finest details are shown regardless of your viewing angle. This is a great advantage if multiple physicians are looking at the screen.
Consistently Secure Image Quality
The optional EIZO RadiCS software to secure image quality enables extensive maintenance and testing of monitors and includes calibration, acceptance and constancy testing, and the archiving of all areas. If you are working on multiple stations, the use of the RadiNET Pro is recommended. This can be used to centrally control the calibration of all monitors, including data history. This saves you a significant amount of time and ensures consistently high image quality across the entire setup. The basic version of RadiCS LE is already included with the RadiForce GX, RX, and MX/MS models.
Observe Monochrome and Color Images on a Single Monitor
The hybrid gamma PXL functionality automatically differentiates between monochrome and color images, pixel by pixel. This creates a hybrid display in which each pixel is displayed with the ideal tone value. In turn, this achieves a greater degree of precision and reliability than conventional planar detection methods.
Blur Reduction
LCD panels with a high brightness level tend to have more blurry image rendering thanks to over-framing than would be possible in comparison with an acquired exposure. Therefore, EIZO offers blur reduction anchored in monitor hardware. It retrieves details lost in the contours on the screen, meaning that the image is rendered as clearly as possible.
One Billion Color Tones Thanks to 13-Bit LUT
Color rendering is controlled by a 13-bit look-up table (LUT), up to 10 bits of which are available in the DisplayPort connection. This produces a resolution with a maximum of 1 billion color tones. The rendering characteristics and fine structures required for diagnostics can therefore be precisely identified.
Uniform Brightness and High Color Purity
The monitor shines thanks to its high color purity and uniform illumination. This is down to the Digital Uniformity Equaliser (DUE), which corrects imbalances automatically, pixel by pixel. Grey and color tones of radiological and other medical images are correctly rendered over the entire display. This is vital for diagnostics.
Balanced Image Quality Thanks to an Integrated Front Sensor
The precise calibration of the white point and tone value characteristic curve is provided by an integrated front sensor (IFS). This measures the brightness and greyscale and calibrates the monitor autonomously according to the DICOM standard. The sensor works automatically, without restricting the field of vision of the monitor. You can save the costs, time, and effort of maintenance and rely on a consistently balanced image quality.
Evolve Your Image Quality: the Work-and-Flow Technology
Radiologists face an increasing amount of information on their screens, as modalities become increasingly digitalized. But imaging procedures now no longer need to be so complex, thanks to the unique Work-and-Flow technology from EIZO, featuring new functions developed especially to meet the requirements of radiologists. The RadiForce RX360 and RadiCS-LE software solutions enable you to benefit from the Work-and-Flow functions.
Point-and-Focus: Easily Select the Analysis Area
The Point-and-Focus function allows you to quickly select and focus on relevant image areas using your mouse or keyboard. By adjusting the brightness and greyscale, you can highlight interesting parts of an image by dimming the surrounding areas.
Switch-and-Go: Straightforward Operation Without Obstacles
The USB conversion takes place within the monitor with the Switch-and-Go function. This allows you to use a single set of keyboards and mice at two different workstations at the same time. You can switch between the two workstations simply by moving the mouse cursor from one screen to the other. This ensures greater work efficiency and allows you to maintain a clear overview of your workstation.
Hide-and-Seek: Fast Retrieval of Information
The Hide-and-Seek function allows you to easily hide whichever PinP windows you are currently not using. You can display the windows when you need them again by moving the mouse cursor to the edge of the screen. This means you can quickly and efficiently display reports, patient files, and other information without needing an additional monitor.
Secure Image Quality Thanks to AAPM/ Euref/ DIN Compliance
The display properties, in particular brightness and contrast, are suited to the creation of image rendering systems compliant with DIN 6868-157. The DICOM® GSDF characteristic is already precisely configured in the factory. This means that greyscales are consistent, which is vital for diagnostics.
Perfectly Designed for Diagnostic Use
Narrow black frontal bezels make this device ideal for use in dark environments. They make it easy to visually concentrate on the display. Meanwhile, a white bezel at the side of the monitor creates a fresh, clean look.
Extended Durations of Use Thanks to Automatic ShutDown
The monitor has an automatic shutdown option for the backlight (backlight saver). This extends the duration of use. Similar to a screen saver, the LEDs turn off when the screen is not being used.
The backlight saver is part of the RadiCS software.
FlexStand: Ergonomic Base
The base allows the monitor to be tilted and turned, as well as operated in landscape or portrait form. The seamless height adjustment starts from the very bottom of the desk. This guarantees optimal ergonomics, regardless of whether you are standing or sitting in front of the screen. Despite its maximum movement possibilities, the FlexStand base always remains completely stable.
One Monitor, Many Ports
It doesn't get easier than this: You can connect most of your devices, such as PC, laptops, or cameras directly to the monitor because the monitor has a number of different ports. That makes your daily work easier.
Multi-Monitor Solutions Without Problems
Thanks to the signal input and output, you can link several RadiForce monitors through their DisplayPort interface. This means that you can realize multi-monitor solutions with the greatest of ease without laborious and excessive cabling.
The ambient Light Sensor Supports the Constancy Test
The sensor integrated into the monitor is used to measure the ambient light and can be used for constancy tests. The prevalent illumination can be determined by the ambient light sensor with the optional RadiCS software.
Constant Brightness During Operation
A sensor for the backlight permanently determines the luminance of the monitor. The benefit: The defined and calibrated values are rendered exactly just seconds after the monitor is turned on and remain constant during the entire period of use. The sensor is invisibly integrated into the monitor.
Reliable Brightness
EIZO is convinced of the quality of its products. The warranty for the monitors, therefore, also covers the brightness stability.
